MIL-PRF-55339/18A
Durability: 500 cycles minimum at 12 cycles/min maximum. The connector shall meet the mating
characteristics and force to engage and disengage requirements.
Dielectric withstanding: Test voltage 1,500 V rms, min (sea level).
Contact resistance (milliohms, max).
Initial
After
Contact
Center
2.0
2.5
Outer
0.5
N/A
Outer (-70001)
1.0
N/A
Vibration, high frequency: Interruptions 1 µs, max.
Shock: Test condition I.
Thermal shock: Test condition C.
Moisture resistance: 200 megohms, min.
Corona level: Voltage 375 V, min.
Altitude - 70,000 feet (4.437 kPa), min.
RF high potential withstanding voltage: RF voltage 1,000 V rms, min.
Frequency 5 MHz, min.
Salt spray (corrosion): Applicable.
Coupling mechanism retention force: 100 lb (444.8 N), min.
Part or Identifying Number (PIN): M55339/18-01034.
PIN: M55339/18-70001. CAUTION: THIS PART HAS A NICKEL PLATED BODY AND IS NOT
FOR USE IN APPLICATIONS WHERE PASSIVE INTERMODULATION GENERATION (PIM) MAY
BE A CONCERN.
Cross reference: See table I.
TABLE I. Cross reference of PIN.
PIN
Superseded PIN or type designation 1/
M55339/18-01034
UG-1034/U
1/ The superseded PIN or the type designation is for cross reference only. Where a
superseded PIN or type designation is not given, none was assigned or will be
assigned. The PIN M55339/18-01034 shall be used in all cases for marking and
identifying the adapter.
Marginal notations are not used in this revision to identify changes with respect to the previous issue due
to the extent of the changes.
3
