MIL-PRF-55339/49A
Contact resistance (milliohms, maximum).
Initial
After environment
Contact
Center
2.0
2.5
Outer
1.5
N/A
Outer (-70001)
3.0
N/A
Vibration, high frequency:
Interruptions: 1 microsecond (µs), max.
Shock: Test condition I.
Thermal shock: Test condition C.
Moisture resistance: 200 megohms, min.
Corona level:
Voltage: 375 V, minimum.
Altitude: 70,000 feet (4.437 kPa), minimum.
RF high potential withstanding voltage:
RF voltage: 1,000 Vrms. minimum.
Frequency: 5 MHz, minimum.
Salt spray (corrosion): Applicable.
Coupling mechanism retention force: 100 lb (444.82 N), minimum.
Part or Identifying Number (PIN): M55339/49-00349 or:
PIN: M55339/49-70001 CAUTION: THIS PART HAS A NICKEL PLATED BODY AND IS NOT
FOR USE IN APPLICATIONS WHERE PASSIVE INTERMODULATION GENERATION (PIM) MAY
BE A CONCERN.
TABLE I. Cross reference of PINs.
Superseded PIN or type designation 1/
PIN
M55339/49-00349
UG-349/U
1/ The superseded PIN or the type designation is for cross reference
only. Where a superseded PIN or type designation is not given,
none was assigned or will be assigned. The PIN M55339/49-00349
shall be used in all cases for marking and identifying the adapter.
4
