MS3116E
Shell size |
L max overall length |
v max closed |
x ID gland seal min range |
Y dia max |
zz screw threads |
Yz (see note 4) Lockwashers NASM35338 or NASM35333 types |
|
closed |
open |
||||||
8 |
2.271 (57.68) |
.187 (4.75) |
.169 (4.29) |
.230 (5.84) |
.828 (21.03) |
6-32 UNG |
NASM35338 - 98 or -41 NASM35333 -105 or -37 |
10 |
.205 (5.21) |
.312 (7.92) |
.891 (22.63) |
||||
12 |
2.411 (61.24) |
.281 (7.14) |
.338 (8.59) |
.442 (11.23) |
1.016 (25.81) |
||
14 |
2.599 (66.01) |
.325 (8.26) |
.416 (10.57) |
.539 (13.69) |
1.161 (29.49) |
||
16 |
2.943 (74.75) |
.356 (9.04) |
.550 (13.97) |
.616 (15.65) |
1.203 (30.56) |
||
18 |
3.172 (80.57) |
.456 (11.58) |
.600 (15.24) |
.672 (17.07) |
1.469 (37.31) |
8-32 UNG |
NASM35338 -B8L or -8L -99 or -42 NASM35333 -106 or -38 |
20 |
3.610 (91.69) |
.519 (13.18) |
.635 (16.13) |
.747 (18.97) |
|||
22 |
3.766 (95.66) |
.670 (17.02) |
.846 (21.49) |
1.656 (42.06) |
|||
24 |
3.985 (101.22) |
.657 (16.69) |
.740 (18.79) |
.894 (22.71) |
1.750 (44.45) |
||
NOTES:
1. Dimensions are in inches.
2. Metric equivalents are given for information only.
3. True position (TP) tolerances specified are in accordance with ASME-Y14.5.
4. Lockwashers may be captivated.
FIGURE 4. Plug, rear accessories configurations, class J.
8
