W-C-596/33D
REQUIREMENTS:
Design and configuration: General grade (see figure 1).
Dimensions: Shall conform to NEMA WD 6, configuration 10-30R.
Rating:
Voltage: 125/250 volts.
Current: 30 amperes.
Frequency: 50/60 hertz.
Mating connector: W-C-596/34
Part or Identifying Number (PIN): W-C-596/33- (dash number from table I).
Supersession and cross reference: See table II.
TABLE I. Dash number.
Dash no.
Supersedes style
Description 1/
1
S1, S2
Single, flush mounted
2
S1, S4
Single, surface mounted
1/ Back wired, side wired or back and side wired.
TABLE II. Supersession and cross reference.
Active
Superseded numbers
Government
CAGE 1/
CAGE
CAGE CAGE CAGE
CAGE
CAGE
CAGE
CAGE
PIN
74545
75582
04009 11419 71183
81091
21873
82379
08556
W-C-596/33-1
9350
5207
9333
2530
9303
3835
3860
1536
160
9344
5207-GY
9344
9340
3853
1536I
9340
5055
9344-I
W-C-596/33-2
388
1535
1440
9395
5054-2
9334
882
3836
9390
5054-2-W
9350
9304
3836-W
3880
1535I
1440-I
5054
3854
161
161A
