W-C-596/40D
REQUIREMENTS
Design and configuration: General grade and hospital grade (see figure 1).
Dimensions: Shall conform to ANSI/NEMA WD 6 configuration 5-20R.
Ratings:
Voltage: 125 volts.
Current: 20 amperes.
Frequency: 50/60 Hertz.
Mating connector: W-C-596/42.
Part or Identifying Number (PIN): WC596/40- (dash number from table I).
TABLE I. Dash number.
Dash number
Supersedes style 1/
Description 2/
Mounting
Color
1
X3, X4, X7, X8
General grade
Box
Ivory
2
X3, X4, X7, X8
General grade
Box
Brown
3
Hospital grade
Box
Ivory
4
Hospital grade
Box
Brown
5
General grade
Snap-in
Ivory
6
General grade
Snap-in
White
7
General grade
Snap-in
Grey
1/ Style X9 is canceled.
2/ Receptacles may have back terminals, side terminals or back and side terminals.
