MIL-DTL-12883/48D
Environmental:
Temperature range: Operating temperature range -70°C to +125°C.
Wire sealing: A resilient grommet is permanently bonded to the wire entry face of the socket so as to
provide moisture sealing capabilities. Wiring sealing range shall be as specified in table II.
TABLE II. Wire sealing range.
Contact
Contact
Wire diameter
size
(mm)
M39029/92-533
.065 min to.109 max
16-16
(2.46 min to 2.77 max)
M39029/5-116
M39029/92-535
.097 min to .142 max
12-12
(2.46 min to 3.60 max)
M39029/5-118
Mechanical:
Vibration (sinusoidal): In accordance with MIL-STD-202, method 204, test condition G, the following
conditions shall apply.
a. Except that the frequency range shall be varied logarithmically between the limits of 10 Hz and
3,000 Hz.
b. Except that the procedure of MIL-STD-202, method 201 may be applied during 10 Hz to 55 Hz
band of the vibration frequency range.
c. Mating relay shall be used as a test gauge.
Vibration (random): In accordance with MIL-STD-1344, method 2005, test condition V, letter G, with a
test duration 15 minutes. The mating relay shall be used as the test gage.
Shock (mechanical): In accordance with MIL-STD-202, method 213, condition C, except peak value
shall be 200 g's.
Insertion and withdrawal forces: The insertion and withdrawal forces of the relay and socket shall be as
specified as in table III.
10
