MIL-DTL-12883/8F
TABLE I. Dash number and characteristics.
Operating temperature
Insulating material
Old type
Dash
ºC
designator
number
1/
-01
200
Ceramic
TS102C02 (2-way)
-02
100
SDG-F, GDI-30F
TS102P02 (1-way)
-03
100
MFE
TS102P02 (2-way)
1/ 1-way replacement: The new item (designated by military part number)
will replace the old item (formerly designated by type designator);
however, the old item will hot replace the new item.
2-way replacement: The new items are interchangeable; i.e., the new
item will replace the old item, and the old item will replace the new item.
Ratings (absolute maximum):
Voltage:
Sea level: 500 volts rms.
50,000 feet (15.24 km): 225 volts rms.
Current: 1 ampere.
Operating temperature: See table I.
Test gage details: See table II and MIL-DTL-12883 (see appendix).
4
