MIL-DTL-12883F
TABLE II. Qualification inspection.
Inspection
Requirement
Method
paragraph
paragraph
Group I (all specimens)
Visual and mechanical inspection
3.1, 3.3, 3.4, 3.6 and 3.7
4.7.1
3.5.1
Insertion and withdrawal force
4.7.2
3.5.2
Insulation resistance
4.7.3
Dielectric withstanding voltage
3.5.3
4.7.4
Gauge retention
3.5.4
4.7.5
Contact resistance
3.5.5
4.7.6
Torque (when specified)
3.5.6
4.7.7
Group II (6 specimens)
Vibration
3.5.7
4.7.8
Mechanical shock (when specified)
3.5.8
4.7.9
Gauge retention
3.5.4
4.7.5
Contact resistance
3.5.5
4.7.6
Humidity
3.5.9
4.7.10
Insulation resistance
3.5.2
4.7.3
Dielectric withstanding voltage
3.5.3
4.7.4
Altitude immersion (when specified)
3.5.16
4.7.17
Salt spray (corrosion)
3.5.15
4.7.16
Resistance to solvents
3.5.17
4.7.18
Group III (6 specimens) 1/
Durability
3.5.10
4.7.11
Insertion and withdrawal force
3.5.1
4.7.2
Gauge retention
3.5.4
4.7.5
Contact resistance
3.5.5
4.7.6
Contact tab flexure (when specified)
3.5.12
4.7.13
Group IV (6 specimens)
Static load (when specified)
3.5.11
4.7.12
Thermal shock (plastic sockets)
3.5.13.1
4.7.14.1
Thermal shock (ceramic sockets)
3.5.13.2
4.7.14.2
Porosity (ceramic sockets only)
3.5.14
4.7.15
Solderability
3.5.18
4.7.19
Group V (all specimens)
Visual and mechanical inspection
4.7.1
3.1, 3.3, 3.4, 3.6 and 3.7
1/ Not required for sockets tested with qualified contacts (example M39029/5-116).
12
