MIL-DTL-12883F
TABLE IV. Group A inspection.
Inspection
Requirement
Method
paragraph
paragraph
Visual and mechanical inspection 1/
3.1, 3.3, 3.4, 3.6, and
4.7.1
Torque (when specified)
3.7
4.7.7
Insertion and withdrawal force 2/
3.5.6
4.7.2
Insulation resistance
3.5.1
4.7.3
Dielectric withstanding voltage
3.5.2
4.7.4
Sea level
3.5.3
4.7.4.1
1/ Only two samples each for physical dimensions. If either of the two
samples fails to meet the requirements, the complete lot sample shall
then be inspected for physical dimensions.
2/ Not required for sockets using qualified contacts.
4.6.1.2.1 Sampling plan. Statistical sampling and inspection for the samples submitted for group A
inspection shall be on a lot by lot basis with sample sizes as listed in table V. Any occurrence of a failure
shall be considered as failure of the lot.
TABLE V. Lot and sample size.
Lot size
Sample
size
1 to 5
all
6 to 50
5
51 to 90
7
91 to 150
11
151 to 280
13
281 to 500
16
501 to 1200
19
1,201 to 3200
23
3,201 to 10000
29
10,001 and over
35
4.6.1.2.2 Rejected lots. If an inspection lot is rejected, the manufacturer may rework it to correct the
defects, or screen out the defective units, and resubmit for reinspection. Resubmitted lots shall be
inspected using tightened inspection and shall not thereafter be tendered for acceptance unless the former
rejection or requirement of correction is disclosed. Such lots shall be separate from new lots and shall be
clearly identified as reinspected lots.
4.6.1.2.3 Disposition of sample units. Sample units, which have passed the entire group A inspections,
may be delivered on the contract if the lot is accepted and the sample units are still within the specification
tolerances.
4.6.2 Periodic inspection. Periodic inspection shall consist of group B. Except where the results of
these inspections show noncompliance with the applicable requirements (see 4.6.2.1.3), delivery of
products, which have passed group A inspection shall not be delayed pending the results of these periodic
inspections.
14
