MIL-DTL-24231/10E(SH)
SAME AS M24231/10-062
EXCEPT AS SHOWN.
24 HOLES.
LOCATION OF HOLES
PACKING, M24231/10-072
SAME AS M24231/10-071.
FIGURE 17. Packing M24231/10-072.
25
SAME AS M24231/10-060
EXCEPT AS SHOWN.
24 HOLES.
LOCATION OF
HOLES SAME
AS M24231/10-071.
POSITIONING PIN
FIGURE 18. Assembly, retainer plate M24231/10-070.
