TABLE I. Parts list Continued.
Quantity for
Item
M24231/10- 3/
2/
no.
Description
Material/specification
Remarks
1/
001
002
003
004
005
40
Pin, contact
14
24
30
40
40
MIL-DTL-24231
See figure 3.
50
Cable, Type LS2SWU-1, 15 ft
MIL-DTL-24643/33
See figure 25.
51
Assembly, retainer plate
1
Ni-Cu, Class A, QQ-N-281
See figure 15 and requirement 5.
52
Assembly, retainer plate
1
Ni-Cu, Class A, QQ-N-281
See figure 18 and requirement 5.
53
Assembly, retainer plate
1
Ni-Cu, Class A, QQ-N-281
See figure 10 and requirement 5.
54
Assembly, retainer plate
1
Ni-Cu, Class A, QQ-N-281
See figure 19 and requirement 5.
55
Assembly, retainer plate
1
Ni-Cu, Class A, QQ-N-281
See figure 22 and requirement 5.
5/
56
Epoxy, resin, molded
As required
Cast epoxy resin, compound
See figure 3.
NOTES:
1/
Item numbers are the same as encircled numbers shown on figures.
2/
See applicable figure or table listed in remarks column for part numbers and dimensions.
3/
Quantity is for one complete assembly of each size.
4/
Nitrile (Buna N); Parker Hannifin Corporation (part number N0756-75), O-ring Division, 2360 Palumbo Drive, Lexington, KY 40509, CAGE 02697, or
equal.
5/
Arco Set 200, M.M. Reif and Co., Ivyland, PA PR610-TCF (Chockfast Orange), ITW Philadelphia Resins Corp., Montgomeryville, PA, or equal.
