MIL-DTL-24231/10E(SH)
C
30 HOLES, Ø674,
L
1
64 X 45° BEVEL,
BOTH SIDES.
4 HOLES, Ø17,
64
1
64 X 45° BEVEL,
POSITIONING PIN, 34
BOTH SIDES.
M24231/5-054, Ø8 X 13 LG.
1
6
FORCE FIT.
C
L
0.062R
0.087 (TYP)
0.146 (TYP)
0.256 (TYP)
0.287 (TYP)
0.362 (TYP)
0.463 (TYP)
0.525 (TYP)
0.087 (TYP)
0.146 (TYP)
0.246 (TYP)
0.368 (TYP)
0.412 (TYP)
0.490 (TYP)
0.543 (TYP)
Ø1.614
1.604
3
32
3
16
Ø1.755
1.745
63
FIGURE 22. Assembly, plate, retainer M24231/10-074.
55
23
