MIL-DTL-24231/18E(SH)
Ø23
4
CABLE, TSP-31
13
OR AS REQD
COMPOUND,
3
POLYURETHANE 14
MIN
2
17
8
45°
ASSEMBLY, PLUG
2
SHELL M24231/21-010
2 MAX
COMPOUND,
17
SOLDER
EPOXY
SEALING WAX 15
COUPLING
7
M24231/21-030
SET SCREW 0.250-20UNC-15 LG,
6
12
CRES HDLS, SOC HD, FULL
DOG POINT
GASKET, O-RING
16
SAE-AS28775-230
BALL BEARING,
11
BRONZE Ø13 (42 REQD)
6
ASSEMBLY, SOCKET
ASSEMBLY, SEALING
8
3
INSERT M24231/18-010
PLUG M24231/18-020
1
FIGURE 1. Connector, plug, 65-conductor.
2
