MIL-DTL-24231/18E(SH)
TABLE I. Parts list.
Quantity for
Item
M24231/18- 3/
2/
no.
Description
Material/specification
Remarks
1/
001
1
Plug, 65-conductor,
1
------
See figure 1.
symbol no. 1139
2
Shell, plug
1
M24231/21-010
See figure 1.
3
Sealing plug assembly
1
See items 4, 5, and 6.
See figure 4 and requirement 2.
Handle, 3/16 thick
4
1
Phosphor bronze, hard, coml
See figure 3.
5
Sealing plug
1
Type II, Grade GV of
See figure 5.
ASTM D1784
6
Screw, F.H.
2
Ni-Cu, Class A, QQ-N-281
See figure 4.
0.312-18UNC-2A, 5/8 long
7
Coupling
1
M24231/21-030
See figure 1.
8
Insert, assembly, socket
1
See items 9, 10, and 14.
See figure 2.
9
Contact, socket
65
MIL-DTL-24231
See requirement 3.
10
Sleeving, socket no. 9,
65
0.118 id by 9/16 long
Category 1, color clear, MIL-I-631
Ball bearing, 3/16 inch
11
42
Bronze, ASTM F2215
See figure 1.
diameter
12
Screw, set, ¼-20UNC by
1
CRES, coml
See figure 1.
/16 Lg handles, soc-hd,
5
full dog point
13
Cable, TSP-31
As required
MIL-DTL-915/22
See figure 1.
4/
14
Compound, polyurethane
As required
See figure 1.
15
Wax, sealing
As required
Coml
See figure 1.
5/
16
Gasket, O-ring
1
SAE-AS28775-230
Lubricate with silicone
compound, SAE-AS8660;
see figure 1.
6/
17
Compound, epoxy
As required
Cast epoxy-resin compound
Base EE4183 or RE2039,
hardener HD-3561; see figure 1.
NOTES:
1/
Item numbers are the same as encircled numbers shown on figures.
2/
See applicable figure or table listed in remarks column for part numbers and dimensions.
3/
Quantity is for one complete assembly of each size.
4/
Molding compound to be procured in accordance with S9320-AM-PRO-020.
5/
Nitrile (Buna N); Parker Hannifin Corporation (part number N0756-75), O-ring Division, 2360 Palumbo Drive,
Lexington, KY 40509, CAGE 02697, or equal.
6/
Hysol base EE4183 or RE2039, hardener HD-3561, Hysol Division, Dexter Corporation, Olean, NY, CAGE 04347,
or equal.
7
