MIL-DTL-24231/19E(SH)
ASSEMBLY, SINGLE CABLE CONNECTOR
M24231/19-001 SYM. NO. 1138
GASKET, O-RING
7
CAP, M24231/22-054 20
SAE-AS28775-236
0.127
ASSEMBLY, SINGLE CBL 2
INSERT, NYLON Ø0.123
11
CONNECTOR BODY
X 0.172 LG TO SUIT
M24231/19-010
M24231/5-077
RING, RETAINING
GASKET, O-RING
14
8
M24231/19-011
SAE-AS28775-334
GASKET, O-RING
9
SAE-AS28775-342
PIN, GUIDE Ø0.125,
19
LG AS REQD
ASSEMBLY, INSERT,
(SEE REQT 3 & 4)
6
MOLDED M24231/20-010
PLATE, RETAINER
5
M24231/19-021
ASSEMBLY, RETAINING 3
PLATE M24231/19-020
PACKING,
12
ASSEMBLY, HULL INSERT
M24231/19-022
M24231/25-003 (NOT
FURNISHED)
WASHER
GASKET, O-RING
10
M24231/19-025 17
SAE-AS28775-339
NUT, ROUND
16
M24231/19-024
RING, RETAINING
15
NUT, GLAND
18
M24231/19-014
M24231/19-023
(SEE REQT 2)
1
SLEEVING 14 I.D.
13
X 0.035 THK, APPROX
10 FEET LONG
1
FIGURE 1. Connector, single cable.
2
