MIL-DTL-24231/19E(SH)
125
HOLES LOCATED SAME
AS INSERT ASSEMBLY
(SEE M24231/20-010)
3
7
Ø64, 65 HOLES
8
1
32 X 45° BEVEL,
BOTH SIDES
Ø 2.520
2.510
FIGURE 6. Plate, retainer M24231/19-021.
5
65 HOLES
RETAINING PLATE
21
(SAME AS RETAINER
PLATE EXCEPT AS
2.770
SHOWN)
2.765
0.192
0.182
0.125R
0.380
PIN, POSITIONING, FORCE FIT
0.123
4
0.370
(2 REQD)
FIGURE 7. Assembly, retaining plate M24231/19-020.
3
7
