MIL-DTL-24231/26E(SH)
C
L
0.192
(TYP)
0.182
C
L
0.380(TYP)
0.370
0.114
(TYP)
0.104
0.224
(TYP)
0.214
0.333
(TYP)
0.323
0.442
(TYP)
0.432
0.552
(TYP)
0.542
COMPOUND,
29
EPOXY RESIN
CABLE
M24231/12-021 28
(7 REQD)
7
16R,
CABLES
EQUALLY SPACED
#6
#7
#5
#1
#2
#4
#3
SAME AS M24231/26-020 EXCEPT AS SHOWN
FIGURE 5. Assembly, insert, molded M24231/26-040.
