MIL-DTL-24231/26E(SH)
TABLE I. Parts list.
Quantity for
Item
M24231/26- 3/
2/
Description
Material/specification
Remarks
no.
1/
001
002
003
1
Connector, single cable,
1
-----
See figure 1.
symbol no. 1270
2
Connector, single cable,
1
-----
See figure 1.
symbol no. 1270.1
3
Connector, single cable,
1
-----
See figure 1.
symbol no. 1270.2
4
Body, connector
1
1
1
M24231/10-040
See figure 1.
4/
5
Gasket, O-ring
1
1
1
SAE-AS28775-329
Lubricate with silicone
compound, SAE-AS8660;
see figure 1.
4/
6
Gasket, O-ring
1
1
1
SAE-AS28775-220
See item 5.
4/
7
Gasket, O-ring
1
1
1
SAE-AS28775-332
See item 5.
4/
8
Gasket, O-ring
1
1
1
SAE-AS28775-334
See item 5.
9
Insert, molded
1
See items 12, 28, and 29.
See figure 2.
10
Insert, molded
1
See items 12, 28, and 29.
See figure 3.
11
Insert, molded
1
See items 12, 28, and 29.
See figure 5.
12
Pin, contact
14
14
24
MIL-DTL-24231
See figure 2.
13
Insert
1
1
1
M24231/5-077
See figure 1.
14
Retainer, plate assembly
1
1
1
M24231/11-020
See figure 1.
15
Ring, retaining
1
1
1
M24231/10-041
See figure 1.
16
Ring, retaining
1
1
1
M24231/10-045
See figure 1.
17
Cap, pressure-proof
1
1
1
M24231/14-011
See figure 1.
18
Plate, retainer
1
1
1
M24231/11-021, Type J
See figure 1 and
requirement 2.
19
Pin, guide
1
1
1
M24231/5-071
See figure 1.
20
Screw
2
2
2
M24231/5-083
See figure 1.
21
Washer
1
1
1
M24231/10-043
See figure 1.
22
Nut
1
1
1
M24231/10-042
See figure 1.
23
Nut, gland
1
1
1
M24231/10-044
See figure 1.
24
Sleeving
15 ft 15 ft
M24231/10-011
See figure 1.
25
Sleeving
15 ft M24231/10-021
See figure 1.
26
Packing
1
1
1
M24231/10-011, Type J
See figure 1.
27
Plate, identification
1
1
1
CRES or Al,
See figure 4.
MIL-DTL-15024
28
Cable, LS2SWU-1, 15 ft
3
4
7
M24231/12-021,
See requirements 3 and 4.
MIL-DTL-24643/33
7
