MIL-DTL-24231/28C(SH)
STAMP OR ENGRAVE
1
IN 8 (MIN) HIGH LTR
0.750
M24231/28-____ REV
010, 020, 030
63
CURRENT REV LETTER AT
63
TIME OF MANUFACTURE
1
16R
C
63
B
A
1
UNDERCUT
8
63
0.054R
M
E
L
F
D
G
H
J
K
ALL OVER
125
EXCEPT AS SHOWN
9
64R
HULL INSERT PLUG - TABLE OF DIMENSIONS
H+0.005
0.000
D+0.000
0.005
PLUG PC NO.
C
G
J
A
B
E
F
K
L
M
-
-
23
115
M24231/28-010 6.625 5.875 2.219
0.068
1.750-12UN-2A 1.550 1.625
0.185
1.750
2.000
4
6
33
115
M24231/28-020 7.125 6.375 2.469
0.086
2.375-12UN-2A 2.145 2.250
0.185
2.375
2.625
8
6
1
113
M24231/28-030 7.000 6.250 1.721
0.103
3.250-12UN-2A 2.980 3.125
0.291
3.250
3.605
42
32
FIGURE 2. Plug, hull insert.
3
