MIL-DTL-24231/28C(SH)
TABLE I. Parts list.
Quantity for
Item
M24231/28- 3/
2/
Description
Material/specification
Remarks
no.
1/
001
002
003
1
Insert assembly, plug
1
-----
See figure 1.
2
Insert assembly, plug
1
-----
See figure 1.
3
Insert assembly, plug
1
-----
See figure 1.
4
Insert plug, M24231/28-010
1
Ni-Cu-Al, QQ-N-286
See figure 2.
5
Insert plug, M24231/28-020
1
Ni-Cu-Al, QQ-N-286
See figure 2.
6
Insert plug, M24231/28-030
1
Ni-Cu-Al, QQ-N-286
See figure 2.
7
Ring, retaining
1
M24231/5-076
See figure 1.
8
Ring, retaining
1
M24231/10-045
See figure 1.
9
Ring, retaining
1
M24231/19-014
See figure 1.
10
Nut
1
M24231/5-074
See figure 1.
11
Nut
1
M24231/10-042
See figure 1.
12
Nut
1
M24231/19-024
See figure 1.
13
Washer
1
M24231/5-075
See figure 1.
14
Washer
1
M24231/10-043
See figure 1.
15
Washer
1
M24231/19-025
See figure 1.
4/
16
Gasket, O-ring, outboard
1
SAE-AS28775-329
Lubricate with silicone
compound, SAE-AS8660;
see figure 1.
4/
17
Gasket, O-ring, outboard
1
SAE-AS28775-334
See item 16.
4/
18
Gasket, O-ring, outboard
1
SAE-AS28775-342
See item 16.
4/
19
Gasket, O-ring, inboard
1
SAE-AS28775-327
See item 16.
4/
20
Gasket, O-ring, inboard
1
SAE-AS28775-332
See item 16.
4/
21
Gasket, O-ring, inboard
1
SAE-AS28775-339
See item 16.
NOTES:
1/
Item numbers are the same as encircled numbers shown on figures.
2/
See applicable figure or table listed in remarks column for part numbers and dimensions.
3/
Quantity is for one complete assembly of each size.
4/
Nitrile (Buna N); Parker Hannifin Corporation (part number N0756-75), O-ring Division, 2360 Palumbo
Drive, Lexington, KY 40509, CAGE 02697, or equal.
