MIL-DTL-24231E(SH)
APPENDIX A
TABLE A-XIV. Connections for 40-conductor plug for 2SWU-19 cable Continued.
Socket no.
Color
Shielded pair no.
36
Black
37
White
18
Shield
38
38
Shield
39
Black
19
40
White
A.3.6 Cable types for molded plugs. Table A-XV lists the cable types which, for molded plugs installed on the
listed systems, require the shield to be cut back with the cable sheathing rather than soldering of the shield to a pin.
TABLE A-XV. Cable types for molded plugs.
System
Cable type (MIL-DTL-915/8)
Hyd/Trans
DT-287, DT-288, DT-333
DT-344, DT-506, DT-531
AN/BQA-8 SERIES
FSS-2
DT-513
AN/BQC-1 SERIES
DSS-3
AT-385, TR-122A, TR-122B
DT-168, DT-168A, DT-168B
AN/BQR-2 SERIES
DSS-3
DT-532
AN/BQR-7 SERIES
DSS-3
DT-211, DT-211A, DT-276
AT-186A, AT-186B, AT-186C
TR-193, TR-193A, TR-193B
AN/UQC-1 SERIES
DSS-3
TR-230
AT-200, AT-200A, AT-200B
AN/UQN-SERIES
DSS-3/4
AT-200D, AT-200C, TR-192
AT-200E, TR-192A, AT-200F
AN/UQN-1 & 4 SERIES
DSS-3/4
AT-200G, TR-192B, TR-256
AN/WQC-2/2A
DSS-3
TR-232, TR-233
AN/BQN-13
DSS-3
AN-BQN-13
A.4 TECHNICAL MANUAL
A.4.1 Molding processes. For information concerning installation, maintenance, and repair of item or
assemblies described in this specification, see S9320-AM-PRO-020.
