MIL-DTL-24231E(SH)
APPENDIX A
A.3.5 Connections for 40-conductor plug for 2SWU-19 cable. Table A-XIV lists the connections for the 40-
conductor plug for 2SWU-19 cable.
TABLE A-XIV. Connections for 40-conductor plug for 2SWU-19 cable.
Socket no.
Color
Shielded pair no.
1
Black
1
2
White
3
Black
2
4
White
5
Black
3
6
White
7
Black
4
8
White
9
Black
5
10
White
11
Black
6
12
White
13
Black
7
14
White
15
Black
8
16
White
17
Black
9
18
White
19
Black
10
20
White
21
Black
11
22
White
23
Black
12
24
White
25
Black
13
26
White
27
Black
14
28
White
29
Black
30
White
15
31
Shield
31
Shield
32
Black
16
White
33
34
Black
17
35
White
33
