MIL-DTL-24231E(SH)
APPENDIX A
TABLE A-VII. Connections for type TSP-31 cable.
Pair
Color
Socket no.
Black
1
Black and white
White
2
Black
3
Black and red
Red
4
Black
5
Black and green
Green
6
Black
7
Black and orange
Orange
8
Black
9
Black and blue
Blue
10
Black
11
Black and brown
Brown
12
Black
13
Black and grey
Grey
14
Black
15
Black and yellow
Yellow
16
Black
17
Black and purple
Purple
18
Black
19
Black and tan
Tan
20
Black
21
Black and pink
Pink
22
White
23
White and red
Red
24
White
25
White and green
Green
26
White
27
White and orange
Orange
28
White
29
White and blue
Blue
30
White
31
White and brown
Brown
32
White
33
White and grey
Grey
34
White
35
White and yellow
Yellow
36
24
