MIL-DTL-24231E(SH)
FLEXIBLE CABLE
MINIMUM BEND
RADIUS = 3 TIMES
CABLE DIAMETER
CHECK BONDING
CABLE
POLYURETHANE
ROUND EDGE PROBE
(RIGID PLASTIC OR METAL)
WITH NO SHARP EDGES OR
CORNERS. DO NOT USE
SCREWDRIVER.
PRY
METAL PLUG SLEEVE
IF POLYURETHANE MATERIAL PEELS BACK TO REVEAL BARE METAL,
THE PLUG ASSEMBLY SHALL BE REJECTED. REPEAT TEST AT FOUR
DIFFERENT POINTS ALONG CIRCUMFERENCE.
FIGURE 1. Bonding test (nondestructive).
