MIL-DTL-24231E(SH)
APPENDIX A
TABLE A-I. Cross index of mating plugs, receptacles, adapters, and single and multiple cable connectors Continued.
Military
Supersedes
No. of
Wiring
Description
Cables
Use with M24231/
part no.
contacts
table
Drawing Symbol
M24231/
27-001
14
Multi-pin receptacle
2 cond. shield. (3)
11-001
IX, X,
---
1271
XI
27-002
14
Multi-pin receptacle
2 cond. shield. (4)
11-001
---
1271.1
IX, X,
27-003
24
Multi-pin receptacle
2 cond. shield. (7)
11-001
---
1271.2
XI
IX, X,
XI
NOTES:
1/
In accordance with MIL-DTL-915.
2/
Formerly shown in MIL-DTL-915; replaced by 7SS.
3/
Formerly shown in MIL-DTL-23020.
4/
Refer to MIL-C-23020/4 for guidance.
5/
In accordance with MIL-DTL-915/58.
6/
Connections should be made in accordance with the applicable specification.
7/
In accordance with MIL-DTL-24643/33.
8/
This identifies hull inserts for mounting the applicable part.
9/
In accordance with MIL-DTL-24643/38.
A.3.2 Cable connections. Table A-II through table A-XI list the cable connections that should be made to all
plugs and receptacles.
TABLE A-II. Connections for two-pin receptacles and plugs.
Pin
Color
1
Black
2
White
TABLE A-III. Connections for three-pin receptacles and plugs.
Cable/color
Pin
TSS-4 1/
DSS-3
THOF-3
1
Black
Black
Black
2
White
White
White
3
Shld
Red
Red
NOTE:
1/
Shield not connected.
