MIL-DTL-24231E(SH)
APPENDIX A
TABLE A-VI. Connections for type RG-264A/U and RG-264C/U cable.
Type RG-264 A/U cable
Type RG-264 C/U cable
Shield
1
1
Tinned *
Untinned
Shield
2
2
Untinned
Tinned
Shield
3
3
Untinned *
Tinned
Shield
4
4
Untinned
Untinned
Shield
5
5
Tinned
Tinned
Shield
6
6
Untinned
Tinned
Shield
7
7
Untinned
Untinned
Shield
8
8
Untinned
Untinned
9
9
Outer shield
Outer shield
NOTE: Copper shields should be electronically isolated from each other and from ground. Use care in
soldering so as not to damage the insulation.
* With blue marker.
23
