INCH-POUND
MIL-DTL-24308/27E
1 December 2009
SUPERSEDING
MIL-DTL-24308/27D
25 June 2007
DETAIL SPECIFICATION SHEET
CONNECTORS, ELECTRIC, RECTANGULAR, MINIATURE,
POLARIZED SHELL, RACK AND PANEL, INSULATION
DISPLACEMENT, SOCKET CONTACTS, NONENVIRONMENTAL
This specification is approved for use by all Departments and Agencies of the Department of Defense.
The requirements for acquiring the product described herein shall consist of this specification sheet and
MIL-DTL-24308.
SHAPE OPTIONAL
N
.510
MAX
SEE
.125 DIA
TERMINATION VIEW
NOTE 6
.115
M
L ±.015
DESIGN OPTIONAL
.510
MAX
.030
SEE
±.010
DETAIL A
.243
SEE NOTES
FLANGE MAY BE MADE
4 AND 5
OF A SINGLE METAL
THICKNESS
P
10°
TYP
.046
±.010
.311
.112
SINGLE METAL
SPLIT SHELL
THICKNESS
OPTION
OPTION
.100 R
WITHOUT STRAIN RELIEF
TYP
DETAIL A
ENGAGEMENT VIEW
ALTERNATE FLANGE DESIGNS
FIGURE 1. Dimensions and configuration.
AMSC N/A
FSC 5935
