MIL-DTL-24308/27E
REQUIREMENTS:
Design and construction:
Dimensions and configuration: See figure 1 and table I.
Mating connector: MIL-DTL-24308/3, MIL-DTL-24308/4, MIL-DTL-24308/7, MIL-DTL-24308/8,
MIL-DTL-24308/9, MIL-DTL-24308/28.
Conductor accommodation: 28 AWG stranded round conductor flat cable with conductors on .050
inch (1.27 mm) centers.
Contact plating shall be in accordance with MIL-DTL-24308 for solder contacts.
Contact retention: Not applicable.
TABLE I. Dash numbers and characteristics.
Dash
Shell
Number
Dimensions 1/
Number
size
of
L
M
N
P
Insert
contacts
±.015
Max
arrangement
(0.38)
2/
1.213
.984
.769
.643
-01
1
9
A-1-1
(30.81)
(24.99)
(19.53)
(16.33)
1.541
1.312
1.093
.971
A-2-1
-02
2
15
(39.14)
(33.32)
(27.76)
(24.66)
2.088
1.852
1.635
1.511
-03
3
25
A-3-1
(53.04)
(47.04)
(41.35)
(38.38)
2.729
2.500
2.282
2.159
A-4-1
-04
4
37
(69.32)
(63.50)
(57.96)
(54.84)
1/ Metric equivalents are given for general information only.
2/ See MIL-DTL-24308 Appendix A for insert arrangements.
Materials:
Contacts: Any suitably conductive copper based alloy.
Strain relief: Polyester in accordance with ASTM D5927 or MIL-M-24519 or 300 series stainless
steel or an equivalent industry standard.
3
