MIL-DTL-24308/27E
.070
.030
ALTERNATE METHOD
OF SECURING SHELL
1.041
MAX
Inches
mm
Inches
mm
Inches
mm
.010
0.25
.070
1.78
.243
6.17
.015
0.38
.100
2.54
.311
7.90
.030
0.76
.112
2.84
.422
10.72
.046
1.17
.115
2.92
.494
12.55
.050
1.27
.125
3.18
1.030
26.16
NOTES:
1. Dimensions are in inches.
2. Metric equivalents are given for information only.
3. Unless otherwise specified tolerances are ±.005 (0.13 mm) for three place decimals and ±.01 for two
place decimals.
4. Use .041/.039 (1.04/0.99 mm) diameter pin.
5. Depth of hole is .143 (3.6.3 mm) minimum as measured with square ended test pin.
6. Interface - Round conductor flat cable on .050 (1.27 mm) centers.
7. Mating end of contact size 20.
FIGURE 1. Dimensions and configuration - Continued.
2
