MIL-DTL-24308/35 Connectors, Electric, Rectangular, Miniature, Combination Insert Arrangement, Plug, Pin Contacts, Shell Size 4, Size 20 Signal Contacts and Size 8 Power and Shielded, Class G, M, N and D

1 - 2 - 3 - 4 - 5 - 6 - 7 - 8 - 9 - 10 - 11 - 12 - 13 - 14 - 15 - 16 - 17 - 18 - 19 - 20 - 21 - 22 - 23 - 24 - 25 - 26


MIL-DTL-24308/35
TABLE I. PIN and dash numbers - Continued.
Insert
PIN
arrangement
Size 8
Termination
Mounting
(see figure 1)
contact
type
configuration
(see figure 5)
M24308/35-501
0.078
Straight
A
M24308/35-502
0.078
Straight
D
M24308/35-503
0.078
Right angle
B
M24308/35-504
0.078
Right angle
E
M24308/35-505
0.078
Right angle
C
M24308/35-506
0.078
Right angle
F
M24308/35-507
0.125
Straight
A
M24308/35-508
0.125
Straight
D
27W2
M24308/35-509
0.125
Right angle
B
M24308/35-510
0.125
Right angle
E
M24308/35-511
0.125
Right angle
C
M24308/35-512
0.125
Right angle
F
M24308/35-513
Shielded Straight
A
M24308/35-514
Shielded Straight
D
M24308/35-515
Shielded Right angle
B
M24308/35-516
Shielded Right angle
E
24
