MIL-DTL-24308/35 Connectors, Electric, Rectangular, Miniature, Combination Insert Arrangement, Plug, Pin Contacts, Shell Size 4, Size 20 Signal Contacts and Size 8 Power and Shielded, Class G, M, N and D

1 - 2 - 3 - 4 - 5 - 6 - 7 - 8 - 9 - 10 - 11 - 12 - 13 - 14 - 15 - 16 - 17 - 18 - 19 - 20 - 21 - 22 - 23 - 24 - 25 - 26

MIL-DTL-24308/35

PIN example:

M24308/35

-501

Specification sheet number:

Dash number from table I:

Finish:

A = Pure electrodeposited aluminum. 1/

F = Cadmium. 1/

K = Zinc nickel. 1/ 2/

P = Passivated stainless steel. 1/

T = Nickel Fluorocarbon Polymer. 1/ 2/

Z = zinc. 1/

- = nickel 3/ or gold 4/

Class:

G, N, D or M (See MIL-DTL-24308)

NOTES:

1/ Finish for class G or N.

2/ Not for use with class N or M

3/ Finish for class D.

4/ Finish for class M.
