MIL-DTL-24308/37 Connectors, Electric, Rectangular, Miniature, Combination Insert Arrangement, Plug, Pin Contacts, Shell Size 5, Size 20 Signal Contacts and Size 8 Power and Shielded, Class G, M, N and D

1 - 2 - 3 - 4 - 5 - 6 - 7 - 8 - 9 - 10 - 11 - 12 - 13 - 14 - 15 - 16 - 17 - 18 - 19 - 20


MIL-DTL-24308/37
TABLE I. PIN and dash numbers - Continued.
Insert
PIN
arrangement
Size 8
Termination
Mounting
(see figure 1)
contact
type
configuration
(see figure 5)
M24308/37-201
0.078
Straight
A
M24308/37-202
0.078
Straight
D
M24308/37-203
0.078
Right angle
B
M24308/37-204
0.078
Right angle
E
M24308/37-205
0.078
Right angle
C
M24308/37-206
0.078
Right angle
F
M24308/37-207
0.125
Straight
A
M24308/37-208
0.125
Straight
D
43W2
M24308/37-209
0.125
Right angle
B
M24308/37-210
0.125
Right angle
E
M24308/37-211
0.125
Right angle
C
M24308/37-212
0.125
Right angle
F
M24308/37-213
Shielded Straight
A
M24308/37-214
Shielded Straight
D
M24308/37-215
Shielded Right angle
B
M24308/37-216
Shielded Right angle
E
17
