MIL-DTL-24308/37 Connectors, Electric, Rectangular, Miniature, Combination Insert Arrangement, Plug, Pin Contacts, Shell Size 5, Size 20 Signal Contacts and Size 8 Power and Shielded, Class G, M, N and D

1 - 2 - 3 - 4 - 5 - 6 - 7 - 8 - 9 - 10 - 11 - 12 - 13 - 14 - 15 - 16 - 17 - 18 - 19 - 20


MIL-DTL-24308/37
TABLE I. PIN and dash numbers - Continued.
Insert
PIN
arrangement
Size 8
Termination
Mounting
(see figure 1)
contact
type
configuration
(see figure 5)
M24308/37-301
0.078
Straight
A
M24308/37-302
0.078
Straight
D
M24308/37-303
0.078
Right angle
B
M24308/37-304
0.078
Right angle
E
M24308/37-305
0.078
Right angle
C
M24308/37-306
0.078
Right angle
F
M24308/37-307
0.125
Straight
A
M24308/37-308
0.125
Straight
D
47W1
M24308/37-309
0.125
Right angle
B
M24308/37-310
0.125
Right angle
E
M24308/37-311
0.125
Right angle
C
M24308/37-312
0.125
Right angle
F
M24308/37-313
Shielded Straight
A
M24308/37-314
Shielded Straight
D
M24308/37-315
Shielded Right angle
B
M24308/37-316
Shielded Right angle
E
18
