MIL-DTL-2726/12B
Design: Housing and insulation may be a one-piece molded unit.
Gasket: Neoprene, commercial (COML), durometer number 20. Lubricate with silicon compound.
O-ring: as specified in SAE-AS28775.
Electrical rating: 40-ampere, 125-volt, alternating current, 60-hertz.
PIN: M2726/11-001 (metal housing and shell), MS2726/11-002 (plastic body).
Contact finish: Silver plate.
Verification
Verification shall be as specified in MIL-DTL-2726 and table I herein. The first article and
conformance inspections shall consist of the inspections as specified in table I, in the order shown.
TABLE I. First article and quality conformance inspection.
First
Conformance
Inspection
article
X
X
Examination
X
X
Insulation resistance
X
X
Dielectric withstanding Voltage
X
X
Contact resistance
X
Endurance
X
Salt spray
X
Contact resistance
X
Current load
X
Vibration
X
Shock
X
X
Effectiveness of enclosure
X
Dielectric withstanding voltage
X
Mechanical abuse
X
Ball drop impact
X
Strain relief
X
Rockwell hardness
Marginal notations are not used in this revision to identify changes with respect to the previous
issue due to the extent of the changes.
Referenced documents. In addition to MIL-DTL-2726, this document references the following:
ASTM-B441
ASTM-D5948
MIL-DTL-2726/6
MIL-DTL-2726/13
MIL-STD-108
SAE-AS28775
4
