MIL-DTL-2726/44B
REQUIREMENTS
Dimensions and configuration: See figures 1 and 2.
Effectiveness of enclosure: Submersible (15 foot) in accordance with MIL-STD-108.
Material: Spring contacts phosphor bronze, spring temper.
Stuffing tubes size: "J" in accordance with MIL-S-24235/14, PIN M24235/14-008 shall be furnished
and installed in the outlet enclosure and on plug PIN M2726/26-001.
Mating plug: In accordance with MIL-DTL-2726/24, PIN M2726/24-001.
Design: Each receptacle shall have a 25-ampere rating.
Plug: In accordance with MIL-DTL-2726/26, PIN M2726/26-001.
Cable: Length 75 feet, shall be 3 conductor, rated at 600-volt, type G, having a ground wire in
each of the three interties between the power conductors. The total circular mil area
of the three ground wires to be equal to that of one of the power conductors.
Electrical rating: 60-ampere, 500-volt alternating current, 60-hertz.
PIN: M2726/44-001 (receptacle assembly).
M2726/44-002 (receptacle).
VERIFICATION
Verification shall be as specified in MIL-DTL-2726 and table I herein. The first article and
conformance inspections shall consist of the inspections as specified in table I, in the order shown.
TABLE I. First article and quality conformance inspection.
First
Conformance
Inspection
article
X
Examination
X
Insulation resistance
X
X
Dielectric withstanding voltage
X
X
X
X
Contact resistance
X
Current load
X
Endurance
X
Salt spray
X
Contact resistance
X
Vibration
X
Shock
X
X
Effectiveness of enclosure
X
Dielectric withstanding voltage
X
X
Leakage current
5
