MIL-DTL-2726/67B
Receptacle material: Spring contact, phosphor bronze spring temper.
Base type MAI-60 In accordance with ASTM-D5948.
Ground screw shall be finished in a distinctive green color.
Enclosure: Material may be molded plastic type MAI-60 In accordance with ASTM-D5948.
Enclosure shall be in accordance with MIL-E-24142, Part or Identifying Number (PIN): M24142/5-002.
Design: Enclosure cover and receptacle assembly may be a one-piece molded unit.
Cap material: Brass or plastic. Intended use, maintain degree of enclosure when plug is removed.
Mating plug: MIL-DTL-2726/68, PIN M2726/68-001.
Electrical rating: 10-ampere, 125-volt, alternating current, 60-hertz.
PIN: M2726/67-001 (receptacle assembly).
M2726-67-002, (receptacle assembly).
VERIFICATION
Verification shall be as specified in MIL-DTL-2726 and table I herein. The first article and
conformance inspections shall consist of the inspections as specified in table I, in the order shown.
TABLE I. First article and conformance inspection.
Inspection
First article
Conformance
Examination
X
X
Insulation resistance
X
X
Dielectric withstanding voltage
X
X
Contact resistance
X
X
Current load
X
Endurance
X
Salt spray
X
Contact resistance
X
Vibration
X
Shock
X
Effectiveness of enclosure
X
X
Dielectric withstanding voltage
X
Marginal notations are not used in this revision to identify changes with respect to the previous issue due
to the extensiveness of the changes.
Referenced documents. In addition to MIL-DTL-2726, this document references the following:
ASTM-D5948
MIL-DTL-2726/68
MIL-E-24142
MIL-STD-108
4
