MIL-DTL-2726/68D
Design: Binding head screws may be used. Individual pathways through the contact insulation shall
be provided to each contact of ample size to accept the insulated conductors.
Screw for ground contact terminal shall be furnished in a distinctive green color.
Electrical rating: 10-ampere, 125-volt, 3-phase, grounded.
PIN: M2726/68-001 (plug assembly).
M2726-68-002 (plug tip).
VERIFICATION
Verification shall be as specified in MIL-DTL-2726 and table I herein. The first article and conformance
inspections shall consist of the inspections as specified in table I, in the order shown.
TABLE I. First article and conformance inspection.
Inspection
First article
Conformance
Examination
X
X
Insulation resistance
X
X
Dielectric withstanding voltage
X
X
Contact resistance
X
X
Current load
X
Endurance
X
Salt spray
X
Contact resistance
X
Current load
X
Vibration
X
Shock
X
Effectiveness of enclosure
X
X
Dielectric withstanding voltage
X
Mechanical abuse
X
Strain relief
x
Marginal notations are not used in this revision to identify changes with respect to the previous issue due
to the extensiveness of the changes.
Referenced documents. In addition to MIL-DTL-2726, this document references the following:
ASTM-D5948
MIL-DTL-24643/3
MIL-DTL-2726/67
MIL-S-19622/3
MIL-S-19622/18
MIL-STD-108
