MIL-DTL-28748/4F
For superseded insert Military Standard sheet PIN's to M28748 PIN's see table III.
TABLE III. Supersession data (inserts).
Number of contact
MS PIN
M28748/4 PIN
positions
MS14011-1
M28748/4-A0001L
7
MS14006-1
M28748/4-B0001L
9
MS18175-1
M28748/4-C0001L
14
MS18177-1
M28748/4-D0001L
20
MS14005-1
M28748/4-E0001L
26
MS18179-1
M28748/4-F0001L
34
MS18181-1
M28748/4-G0001L
42
MS18183-1
M28748/4-H0001L
50
MS18185-1
M28748/4-J0001L
66
MS18188-1
M28748/4-K0001L
75
MS18190-1
M28748/4-L0001L
104
34 1/
MS18178-2
M28748/4-M0001L
42 1/
MS18181-2
M28748/4-N0001L
50 1/
MS18183-2
M28748/4-P0001L
66 1/
MS18185-2
M28748/4-Q0001L
75 1/
MS18188-2
M28748/4-R0001L
104 1/
MS18190-2
M28748/4-S0001L
1/ Insert through hole designator. Inserts -2 (M through S) have
through holes for use with long one-piece jackscrew designs only.
Marginal notations are not used in this revision to identify changes with respect to the previous issue due
to the extent of the changes.
Reference documents. In addition to MIL-DTL-28748, this document references the following:
MIL-DTL-28748/1
MIL-DTL-28748/3
MIL-DTL-28748/17
16
