MIL-DTL-28748/5E
For superseded insert Military Standard sheet PIN's to M28748 PIN's see table II.
TABLE II. Supersession data (inserts).
Number of contact
MS PIN
M28748/5 PIN
positions
7
M28748/5-A0001L
MS24004-1
9
M28748/5-B0001L
MS18275-1
14
M28748/5-C0001L
MS24010-1
18
M28748/5-S0001L
MS24012-1
20
M28748/5-D0001L
MS24014-1
26
M28748/5-E0001L
MS24020-1
34
M28748/5-F0001L
MS24022-1
42
M28748/5-G0001L
MS18258-1
50
M28748/5-H0001L
MS24026-1
75
M28748/5-J0001L
MS18261-1
104
M28748/5-K0001L
MS18263-1
34 1/
M28748/5-M0001L
MS24022-2
M28748/5-N0001L
MS18258-2
42 1/
M28748/5-P0001L
MS24052-2
50 1/
M28748/5-Q0001L
MS18261-2
75 1/
M28748/5-R0001L
MS18263-2
104 1/
1/ Insert through hole designator. Inserts -2 (M through S) have
through holes for use with long one-piece jackscrew designs only.
Marginal notations are not used in this revision to identify changes with respect to the previous issue
due to the extent of the changes.
Reference documents. In addition to MIL-DTL-28748, this document references the following:
MIL-DTL-28748/4
MIL-DTL-28748/6
MIL-DTL-28748/17
