MIL-DTL-39024/11G
terminals. Existing government stocks of non-gold terminal items shall be issued until exhausted.
However, only "G" suffix items will be purchased. "G" suffix may be added to existing M39024/11-XX
PIN's Lacking "G" suffix. New NSNs will not be assigned.
Operating conditions:
Operating voltage: 1,500 volts rms, 60 hertz at sea level; 350 volts rms, 60 hertz at 50,000 feet.
Maximum thickness of unsupported printed wiring board on which the connector may be used is .0625
inch (1.588mm). Maximum thickness of printed wiring board with plated through hole is .0930 inch
(2.352mm).
Qualification: Not applicable.
Conformance inspection. Groups A and B tests in accordance with MIL-DTL-39024 shall be
applicable.
Substitution data. See table II.
TABLE II. Substitution data.
Deleted dash numbers
Recommended substitute
(dash numbers)
-21
-01
-22
-02
-23
-03
-24
-04
-25
-05
-26
-06
-27
-07
-28
-08
-29
-09
-30
-10
Changes from previous issue. The margins of this specification are marked with vertical lines to indicate
where changes from the previous issue were made. This was done as a convenience only and the
Government assumes no liability whatsoever for any inaccuracies in these notations. Bidders and
contractors are cautioned to evaluate the requirements of this document based on the entire content
irrespective of the marginal notations and relationship to the last previous issue.
