MIL-DTL-55302/32G
REQUIREMENTS:
Design and construction:
Dimensions and configuration: See figure 1.
Material: Contact material shall be in accordance with MIL-DTL-55302 or beryllium copper alloy C17410 in
accordance with ASTM B768.
Plating (contact):
Engagement area: Gold over .100 inch (2.54 mm) length over nickel in accordance with MIL-DTL-55302.
Termination area: Tin lead for .220 inch (5.59 mm) length over nickel in accordance with MIL-DTL-55302.
Other areas: Nickel-plated in accordance with MIL-DTL-55302.
PINs M55302/32-02 through M55302/32-07: Entire part shall be plated with gold over nickel in accordance
with MIL-DTL-55302.
Qualification and quality conformance: Qualification and quality conformance requirements are not applicable. All
contacts are tested in accordance with the applicable specification sheet.
Supersession data: See table I.
TABLE I. Supersession data.
Superseding PIN
Superseded manufacturer's
M55302/32-
(CAGE 00779)
PIN
01
583218-3
02
2-583812-6
03
2-583812-8
04
3-583812-0
05
1-446629-4
06
1-446629-6
07
1-446629-8
Application: Contacts, solder eyelet, are to be used with connectors in accordance with MIL-DTL-55302/24,
MIL-DTL-55302/25, and MIL-DTL-55302/27, (type II). Contacts, wrappost, are to be used with connectors in
accordance with MIL-DTL-55302/27 (types V and VI) and MIL-DTL-55302/130 (type 2).
