MIL-DTL-55302/78D
NOTES:
1. Indicated dimension applies for indicated length.
2. Material is in accordance with L-P-410 (nylon 6/6).
3. Installs in MIL-DTL-55302/77.
Bushing, polarization, octagon, molded
Inches
mm
Inches
mm
Inches
mm
Inches
mm
Inches
mm
.001
0.03
.015
0.38
.037
0.94
.096
2.44
.160
4.06
.0015
0.038
.016
0.41
.039
0.99
.105
2.67
.172
4.37
.002
0.05
.018
0.46
.040
1.02
.1060
2.692
.180
4.57
.003
0.08
.022
0.56
.050
1.27
.121
3.07
.182
4.62
.004
0.10
.025
0.64
.058
1.47
.128
3.25
.224
5.69
.005
0.13
.026
0.66
.062
1.57
.129
3.28
.264
6.71
.007
0.18
.031
0.79
.072
1.83
.130
3.30
.335
8.51
.010
0.25
.032
0.81
.073
1.85
.141
3.58
.420
10.67
.093
2.36
.148
3.76
.461
11.71
NOTES:
1. Dimensions are in inches.
2. Metric equivalents are given for information only.
3. Unless otherwise specified, tolerances are ±.010 (0.25 mm).
FIGURE 1. Key polarizing - Continued.
