MIL-DTL-83502/2G
64.011°
78.759°
Y DIA
SEE NOTE 4
Y DIA
X DIA
X DIA
SEE NOTE 3
Busing minor
"X" Diameter
diameter
"Y" Diameter
Hole or punch
(see figure 1)
Inches
mm
Inches
mm
Inches
mm
3.73
9.47
.380
9.65
.366/.369
9.30/9.37
+.007
+0.18
+.010
+0.25
±.002
±0.05
-.003
-0.08
-.000
-0.00
NOTES:
1. For recommended installation procedure drill or punch hole in chassis for press-fit of socket.
2. For printed circuit mounting drill holes to accept terminals.
3. Use 60° countersink for chassis thickness .040 inch (1.02 mm) and over.
4. Use 82° countersink for chassis thickness .039 inch (1.02 mm) and under.
5. Dimensions are in inches.
6. Metric equivalents are given for general information only.
7. Metric equivalents are in parentheses.
FIGURE 2. Recommend mounting.
6
