MIL-DTL-83502/2G
TABLE I. Dash numbers and characteristics.
Dash number
Number
Termination
Mating force
Retention
M83502/2-
of
type
(maximum)
force
contacts
lbs (kg)
(minimum)
lbs (kg)
002
3
II
4.0 (1.81)
4.5 (2.04)
003
3
III
4.0 (1.81)
4.5 (2.04)
004
3
IV
4.0 (1.81)
4.5 (2.04)
006
4
II
4.0 (1.81)
4.5 (2.04)
007
4
III
4.0 (1.81)
4.5 (2.04)
008
4
IV
4.0 (1.81)
4.5 (2.04)
010
6
II
2.5 (1.13)
3.0 (1.36)
011
6
III
2.5 (1.13)
3.0 (1.36)
012
6
IV
2.5 (1.13)
3.0 (1.36)
014
8
II
2.5 (1.13)
3.0 (1.36)
015
8
III
2.5 (1.13)
3.0 (1.36)
016
8
IV
2.5 (1.13)
3.0 (1.36)
018
10
II
2.5 (1.13)
3.0 (1.36)
019
10
III
2.5 (1.13)
3.0 (1.36)
020
10
IV
2.5 (1.13)
3.0 (1.36)
022
10
II
2.5 (1.13)
3.0 (1.36)
REQUIREMENTS:
Dimensions and configurations: See figure 1 and table I.
Recommend mounting: See figure 2.
Reference material: See MIL-DTL-83502.
Body: PTFE (polytetrafluoroethylene) rod in accordance with ASTM D1710.
Contact: Beryllium Copper in accordance with ASTM B139, ASTM B194, ASTM B103, or
UNS C729000 spinodal alloy in accordance with ASTM B740.
Contact finish: Gold over nickel in accordance with MIL-DTL-83502.
Terminal: Brass in accordance with ASTM B16.
These sockets are intended for use on .093 inch (2.36 mm) nominal printed circuit boards.
