MIL-DTL-83505/1F
B
C
A
C
.0012 MAXIMUM PERMISSIBLE
DIVIATION FROM SQUARE OR
RECTANGLE
.BURR .0015 MAX
.003 R MAX
Inches
mm
.0012
0.030
.0015
0.038
.003
0.076
A
B
C
Parallelism
Straightness
(mm)
(mm)
(mm)
(mm)
Inch/inch (mm)
.025 (0.63) nominal
.025 (0.63) nominal
.0355 (0.902) max
.002
.005
.022 (0.56) min
.022 (0.56) min
.0325 (0.825) min
(0.05)
(0.13)
NOTES:
1. Dimensions are in inches.
2. Metric equivalents are given for general information only.
FIGURE 2. Wrappost geometry.
3
