MIL-DTL-83505/1F
MINIMUM
WRAPPABLE
LENGTH "B"
MINIMUM WRAPPABLE LENGTH, -B, INCHES
(see note 5)
Number
Wire gauge (AWG)
of
wrapped
30
28
26
24
22
20
18
connections
.185
.219
.226
.258
.303
.327
.391
1
(4.70)
(5.56)
(5.74)
(6.55)
(7.70)
(8.31)
(9.93)
.320
.388
.402
.466
2
(8.13)
(9.86)
(10.21)
(11.84)
.455
3
(11.56)
NOTES:
1. Dimensions are in inches.
2. Metric equivalents are given for general information only.
3. Metric equivalents are in parentheses.
4. Unless otherwise specified the tolerance is ± .005 inch (0.13 mm).
5. Minimum wrappable length shall have the wrappost geometry in accordance with figure 2.
FIGURE 3. Wrappost configurations and wire gauge wrappable length.
4
