MIL-DTL-83513/16D
B
C
Number
F
G
A
E
+.007
+.005
D
of
Max
Max
Max
contacts
(.18mm)
(.13mm)
9
1.390
1.150
.565
.3338
.1848
.465
.325
(35.31)
29.21)
(14.35)
(8.48)
(4.70)
(11.81)
(8.26)
15
1.540
1.30
.715
.4838
.1848
.465
.325
(39.12)
(33.02)
(18.16)
(12.29)
(4.70)
(11.81)
(8.26)
21
1.690
1.450
.865
.6338
.1848
.465
.325
(42.93)
(36.83)
(21.97)
(16.10)
(4.70)
(11.81)
(8.26)
25
1.790
1.550
.965
.7338
.1848
.465
.325
(45.47)
(39.37)
(24.51)
(18.64)
(4.70)
(11.81)
(8.26)
31
2.040
1.800
1.115
.8838
.1848
.465
.325
(51.82)
(45.72)
(28.32)
(22.45)
(4.70)
(11.81)
(8.26)
37
2.340
2.100
1.265
1.0338
.1848
.465
.325
(59.44)
(53.34)
(32.13)
(26.26)
(4.70)
(11.81)
(8.26)
NOTES:
1. Dimensions are in inches.
2. Metric equivalents are given for information only.
3. Unless otherwise specified, tolerances are .005 (0.13 mm).
4. Termination organization area to be optionally molded or filled with a potting fill material capable of passing the
electrical and environmental requirements of MIL-DTL-83513. Plastic molding shall conform to type GDI-30F or
type SDG-F in accordance with ASTM D5948 or GCT-30F in accordance with ASTM D5927 or MIL-M-24519 or
GST-40F in accordance with ASTM D4067 or MIL-M-24519 or GLCP-30F or GLCP-50 in accordance with
ASTM D5138 or MIL-M-24519.
5. Metal shell shall be of material in accordance with MIL-DTL-83513 for class M parts.
6. Jackpost (securely attached) when specified: Corrosion resistant steel in accordance with
ASTM A484/A484M and ASTM A582/A582M, 300 series stainless steel, passivated in accordance with
SAE-AMS-2700, type 2. Hardware will be attached in such a fashion as to not loosen during normal de-mating
conditions, where as, the mating connector hardware does not exceed the following torque values: 2.5 inch
pounds for #2-56 (arrangements A G) and 4.5 inch pounds for #4-40 (arrangement H).
7. Separately molded plastic body (if used) shall conform to type GDI-30F or type SDG-F in accordance with
ASTM D5948 or GCT-30F in accordance with ASTM D5927 or MIL-M-24519 or GST-40F in accordance with
ASTM D4067 or MIL-M-24519 or GLCP-30F or GLCP-50 in accordance with ASTM D5138 or MIL-M-24519.
8. Wire termination pins shall conform to A-A-59551, number 24 AWG copper, except shall be tin-lead plated with
a minimum of 3 percent lead.
9. Termination lengths available: .109 (2.77 mm), .140 (3.56 mm) or .172 (4.37 mm). The tolerance shall be
.015 (0.381 mm) for all termination lengths.
10. Threaded insert, when specified: Corrosion resistant steel in accordance with ASTM A484/A484M and ASTM
A582/A582M, 300 series stainless steel, passivated in accordance with SAE-AMS-2700, type 2.
FIGURE 1. Connector, plug, 050 inch (1.27 mm) spacing - Continued.
