MIL-DTL-83513/16D
REQUIREMENTS:
Dimensions and configurations: See figures 1, 2 and 3.
Current rating, maximum: 3 amperes per contact.
Materials:
Termination organization area: Potting fill material capable of passing the electrical and environmental
requirements of MIL-DTL-83513.
Shell: The requirements for shell materials shall be in accordance with MIL-DTL-83513.
Plastic body or plastic molding: Shall conform to the requirements of GDI-30F or type SDG-F in accordance with
ASTM D5948 or GCT-30F in accordance with ASTM D5927 or MIL-M-24519 or GST-40F in accordance with
ASTM D4067 or MIL-M-24519 or GLCP-30F or GLCP-50 in accordance with ASTM D5138 or MIL-M-24519.
Jackpost: Corrosion resistant steel in accordance with ASTM A484/A484M and ASTM A582/A582M, 300 series
stainless steel, passivated in accordance with SAE-AMS-2700, type 2.
Wire termination pins: Wire termination pins shall conform to A-A-59551, no. 24 AWG copper, except shall be tin-
lead plated with a minimum of 3 percent lead.
Mating connector: Shall conform to MIL-DTL-83513/2 and MIL-DTL-83513/4.
Plating of termination leads: Solder dipping of termination leads will be accomplished in SN60 PB40 or SN63 PB37
in accordance with J-STD-006.
Part or Identifying Number (PIN): PIN shall consist of the letter M, the basic number of the specification sheet, a
letter from the insert, a numerical code for the termination length, and a letter code for the shell finish and hardware
column.
M83513/16-
A
01
A
P
Termination
Shell finish
Hardware
Specification
Insert
length
(interface critical)
sheet number
arrangements
(see figure 2)
A = 09
01 = .109
A = Pure electrodeposited
N = No hardware or threaded insert
B = 15
02 = .140
aluminum
P = jackpost attach
C = 21
03 = .172
C = Cadmium
T = threaded insert
D = 25
K = Zinc nickel
W = jackpost and threaded insert
E = 31
N = electroless nickel
F = 37
(space applications only)
P = Passivated Stainless Steel
T = Nickel fluorocarbon
polymer
Changes from previous issue: The margins of this specification are marked with vertical lines to indicate where
changes from previous issue were made. This was done as a convenience only and the Government assumes no
liability whatsoever for any inaccuracies in these notations. Bidders and contractors are cautioned to evaluate the
requirements of this document based on the entire content irrespective of the marginal notations and relationship to
the last previous issue.
