MIL-DTL-83517/3A
Inches
mm
Inches
mm
.001
.03
.065
1.65
PIN
"A" dim.
.025 ±.002
.002
.05
.100
2.54
M83517/3-31007
.004
.10
.102
2.59
.005
.13
.112
2.84
.006
.15
.162
4.11
.010
.25
.223
5.66
.025
.64
.2405
6.109
.035
.89
.375
9.53
.050
1.27
.4810
12.217
.625
15.88
.630
16.00
NOTES:
1. Dimensions are in inches.
2. Metric equivalents are given for information only.
3. All undimensioned pictorial configurations are for reference purposes only.
4. Number two screws are suggested for mounting.
FIGURE 3. Series SMA, socket contact, (2 hole) flange mounted receptacle, extended contact.
3
