MIL-DTL-83517/6A
Voltage standing wave ratio (VSWR): 1.35 +.01F (F in GHz), maximum.
Test frequency range: From .5 to 18.0 GHz. (Using a test method approved by the qualifying
activity.)
RF transmission loss: .07√F (F in GHz) tested from 2-18 GHz.
RF leakage: Not applicable.
Connector durability:
Interface:
500 cycles minimum at 12 cycles/minute maximum rate.
Connector shall meet contact gaging and force to engage and disengage requirements.
Contact resistance: In milliohms maximum.
Initial
After environment
Center contact:
3.0
4.0
Outer contact:
2.0
Not applicable
Thermal shock: Applicable, test condition A.
Moisture resistance: Method 106 of MIL-STD-202.
No measurements at high humidity. Insulation resistance shall be at least 200 megohms within 5
minutes after removal from humidity.
RF high potential withstanding voltage:
At a frequency between 5 to 7.5 MHz.
Leakage current Not applicable.
RF voltage 670 V rms.
Coupling mechanism retention force: Not applicable.
PIN: M83517/6-(dash number from table I.)
Group qualification: See table II.
TABLE II. Group qualification.
Group
Submission and qualification of any of the following
Qualifies the following
connectors 1/2/
connectors
M83517/6-
M83517/6-
1
3+001
3+001
3+002
1/ Individual connectors other than listed are self qualifying only.
2/ Qualification of connectors, qualifies connectors of the same material only.
+ Denotes finish.
4
